Direct Factories & Quality

Display Engineer modules are manufactured in our direct factories, which build them in-house. Shenzhen PengJi Photoelectricity in Shipai Town, Dongguan, is one of them, with automated COG and FOG bonding, backlight assembly, touch lamination and optical bonding. Modules are electrically and optically inspected and aged before shipment, and new designs pass reliability tests such as temperature cycling and humidity exposure.

Our direct factories

Manufacturing for Display Engineer is backed by these factories. Each product page shows which factory manufactures that module.

Direct factory

Shenzhen PengJi Photoelectricity Co., Ltd.

PengJi is one of Display Engineer's direct factories and backs the manufacturing of Display Engineer modules. It designs and manufactures TFT LCD modules from 0.96″ to 31.5″, together with backlights, capacitive and resistive touch panels and driver boards, in its own industrial park in Dongguan.

Relationship: Direct factory
Location: Shipai Town, Dongguan, Guangdong, China
Founded: 2004
Module sizes: 0.96″–31.5″
Capacity: Up to 3 million modules / month (as published by PengJi)

Automated COG and FOG bonding lines
Backlight assembly, including high-brightness backlights
Capacitive and resistive touch panel lamination
Optical bonding and cover-glass options
Custom FPC, backlight and outline for project volumes

Main building, Dongguan at PengJi Photoelectricity, a Display Engineer direct factory (enhanced from the original photo) — Main building, Dongguan · PengJi

Production workshop at PengJi Photoelectricity, a Display Engineer direct factory (enhanced from the original photo) — Production workshop · PengJi

2004
Company founded in Shenzhen
2008
Factory officially put into production
2013
ISO 9001 and ISO 14001 certification
2017
Industrial park established in Shipai Town, Dongguan

Certificates held by PengJi

National High-Tech Enterprise Certificate 2021
National High-Tech Enterprise Certificate 2018
National High-Tech Enterprise Certificate 2015

Factory photos and certificates courtesy of PengJi Photoelectricity; photos enhanced (upscaled) for display.

From glass to module

A TFT display module is assembled from a TFT glass cell, a driver IC, a flexible circuit, a backlight and, optionally, touch and cover glass. Each step affects yield and long-term reliability, which is why our direct factories run these steps themselves.

Process	What happens	What is controlled
Polarizer attachment	Front and rear polarizers laminated to the cell	Bubbles, particles, alignment
COG bonding	Driver IC bonded to the glass ledge with ACF	Temperature, pressure, ACF particle capture
FOG bonding	FPC bonded to the glass	Alignment, peel strength
Backlight assembly	LEDs, light guide, diffuser and brightness films	Brightness, uniformity, colour point
Module assembly	Cell, backlight and frame combined	Light leakage, mechanical fit
Touch lamination / optical bonding	CTP or cover glass attached with OCA/OCR	Bubbles, Mura, adhesion

Inspection

Electrical test: current consumption, interface function, display patterns.
Optical inspection: dead and bright pixels, lines, Mura, brightness and uniformity against the datasheet limits.
Aging (burn-in): modules run for a defined period before final inspection to screen early failures.

Reliability testing for new designs

Typical qualification tests include high- and low-temperature operation and storage, temperature cycling or thermal shock, high-temperature/high-humidity exposure, and vibration. Test conditions and results are documented in the product's reliability report, available on request with the datasheet.

Documentation we provide

Datasheet, mechanical drawing, reliability report, RoHS/REACH declarations from the producing factory and, for production orders, inspection criteria agreed with your quality team.
