Specifications
| Diagonal size | 3.5" |
|---|---|
| Manufactured by | Shenzhen PengJi Photoelectricity Co., Ltd. (direct factory) |
| Resolution | 480×640 |
| Panel type | TN |
| Interface | MIPI DSI |
| Driver IC | HX8363A |
| Pixel pitch (mm) | 0.111 * 0.111 mm |
| Touch | None |
| Brightness | 200 cd/m² (nits) |
| Viewing angle | 12 O’clock viewing direction |
| Colors | 16.7M |
| Outline (mm) | 67.30 (W) * 96.20 (H) * 3.9(T) mm |
| Active area (mm) | 53.28(W) * 71.04(H) mm |
| Backlight | 6 Serial |
Data sources
- Specifications from the product page of the factory that builds the PJ3506G01-31H30P200C (Shenzhen PengJi Photoelectricity Co., Ltd.).
- Brightness is the standard-backlight typical value encoded in the PengJi part number (e.g. …P400 = 400 cd/m²), cross-checked against PengJi's product table and datasheets; other backlight levels can be built.
- Confirm final values against the datasheet supplied with samples.
Integration calculations
Figures below are calculated from the PJ3506G01-31H30P200C’s 480×640 resolution and MIPI DSI, so you can size the host before requesting samples. Refresh rates are theoretical bus limits; real throughput is lower once command overhead and rendering time are included.
| Pixel density | 229 PPI |
|---|---|
| Native orientation | Portrait (480×640); rotate in the driver for landscape UIs |
| Full frame buffer | 600 KB at RGB565 · 900 KB at RGB888 |
| MIPI DSI bandwidth for 60 Hz (RGB888) | ≈ 0.53 Gbit/s → 0.27 Gbit/s per lane on 2 lanes, 0.13 on 4 lanes |
At 200 cd/m² it is sized for indoor use; the backlight can be upgraded for brighter environments.
Hosts with a native MIPI DSI peripheral
Two 4-lane MIPI connectors usable for DSI.
Native MIPI DSI output.
- ESP32-P4
2-lane MIPI DSI controller.
Interface support is based on each processor’s published display peripherals, not a bench test of this module. Ask us for tested init code.
Alternatives in the catalog
Other 3.5" options
- PJT350P15H50-400P54C3.5" 320×240 · RGB (parallel) · TN · 400 nits
- PJ3502B01-32H54P4003.5" 320×240 · RGB (parallel) · IPS · 400 nits
- PJT350P15H32-400P54N3.5" 320×240 · RGB (parallel) · TN · 400 nits
- PJ3501I01-34H54P3003.5" 320×240 · RGB (parallel) · IPS · 300 nits
- PJ3501I12-22H16P2503.5" 320×480 · SPI · TN · 250 nits
- PJ3501I09-34H40P200R3.5" 320×480 · MCU (8080 parallel) · TN · 200 nits
Frequently asked questions
What is the brightness of the PJ3506G01-31H30P200C?
200 cd/m² typical with the standard backlight. At 200 cd/m² it is sized for indoor use; the backlight can be upgraded for brighter environments.
What interface does the PJ3506G01-31H30P200C use?
MIPI DSI. The driver IC is the HX8363A. Pin definition and timing are in the datasheet, which you can request on this page.
Which processors can drive the PJ3506G01-31H30P200C?
Raspberry Pi 5: Two 4-lane MIPI connectors usable for DSI. Rockchip RK3568: Native MIPI DSI output. ESP32-P4: 2-lane MIPI DSI controller.
What is the MOQ and lead time for the PJ3506G01-31H30P200C?
Samples start from 1 pc. Production MOQ and lead time depend on quantity and any customization (FPC length, backlight, touch), and are agreed per project with our sales team. Send your annual volume and target date for a quote.
