Specifications
| Diagonal size | 7" |
|---|---|
| Manufactured by | Shenzhen PengJi Photoelectricity Co., Ltd. (direct factory) |
| Resolution | 800×480 |
| Interface | HDMI / USB |
| Touch | None |
Data sources
- Specifications from the product page of the factory that builds the 7INCH-RASPBERRY-PI-DISPLAY (Shenzhen PengJi Photoelectricity Co., Ltd.).
- Confirm final values against the datasheet supplied with samples.
Integration calculations
Figures below are calculated from the 7INCH-RASPBERRY-PI-DISPLAY’s 800×480 resolution and HDMI / USB, so you can size the host before requesting samples. Refresh rates are theoretical bus limits; real throughput is lower once command overhead and rendering time are included.
| Pixel density | 133 PPI |
|---|---|
| Native orientation | Landscape (800×480) |
| Full frame buffer | 750 KB at RGB565 · 1.10 MB at RGB888 |
Hosts with a native HDMI / USB peripheral
- Any HDMI source
Raspberry Pi, x86 boards and SBCs; no driver code needed.
Interface support is based on each processor’s published display peripherals, not a bench test of this module. Ask us for tested init code.
Alternatives in the catalog
Other 7" options
- PJ7004I38-57H40P10007" 800×480 · RGB (parallel) · IPS · 1000 nits
- PJ7004I58-57H50P6007" 800×480 · RGB (parallel) · TN · 600 nits
- PJ7003I78-60H40P400C7" 800×480 · RGB (parallel) · TN · 400 nits
- PJ7003I40-35H40P4007" 800×480 · RGB (parallel) · TN · 400 nits
- PJT700P94H57-400P50N7" 800×480 · RGB (parallel) · TN · 400 nits
- PJ7003I04-35H50P3507" 800×480 · RGB (parallel) · TN · 350 nits
800×480 in other sizes
- PJ9002I04-55H50P3509" 800×480 · RGB (parallel) · TN · 350 nits
- PJ5004I06-28H40P3505" 800×480 · RGB (parallel) · TN · 350 nits
- PJ5005I04-29H40P2505" 800×480 · RGB (parallel) · TN · 250 nits
- PJ5004I03-28H40P5005" 800×480 · RGB (parallel) · TN · 500 nits
- PJ5005I02-40H40P300R5" 800×480 · RGB (parallel) · TN · 300 nits
- PJ5005I02-28H40P4005" 800×480 · RGB (parallel) · TN · 400 nits
Frequently asked questions
What interface does the 7INCH-RASPBERRY-PI-DISPLAY use?
HDMI / USB. Pin definition and timing are in the datasheet, which you can request on this page.
Which processors can drive the 7INCH-RASPBERRY-PI-DISPLAY?
Any HDMI source: Raspberry Pi, x86 boards and SBCs; no driver code needed.
What is the MOQ and lead time for the 7INCH-RASPBERRY-PI-DISPLAY?
Samples start from 1 pc. Production MOQ and lead time depend on quantity and any customization (FPC length, backlight, touch), and are agreed per project with our sales team. Send your annual volume and target date for a quote.
