Specifications
| Diagonal size | 1.77" |
|---|---|
| Manufactured by | Shenzhen PengJi Photoelectricity Co., Ltd. (direct factory) |
| Resolution | 128×160 |
| Interface | On request |
| Touch | None |
| Brightness | 300 cd/m² (nits) |
Data sources
- Specifications from the product page of the factory that builds the PJ17702I04-23H12P300 (Shenzhen PengJi Photoelectricity Co., Ltd.).
- PengJi's product page has no spec table for this model; interface, driver IC and outline come with the datasheet. Brightness is the standard-backlight typical value encoded in the PengJi part number (e.g. …P400 = 400 cd/m²), cross-checked against PengJi's product table and datasheets; other backlight levels can be built.
- Confirm final values against the datasheet supplied with samples.
Integration calculations
Figures below are calculated from the PJ17702I04-23H12P300’s 128×160 resolution and interface, so you can size the host before requesting samples. Refresh rates are theoretical bus limits; real throughput is lower once command overhead and rendering time are included.
| Pixel density | 116 PPI |
|---|---|
| Native orientation | Portrait (128×160); rotate in the driver for landscape UIs |
| Full frame buffer | 40 KB at RGB565 · 60 KB at RGB888 |
At 300 cd/m² it is sized for indoor use; the backlight can be upgraded for brighter environments.
Alternatives in the catalog
Frequently asked questions
What is the brightness of the PJ17702I04-23H12P300?
300 cd/m² typical with the standard backlight. At 300 cd/m² it is sized for indoor use; the backlight can be upgraded for brighter environments.
What is the MOQ and lead time for the PJ17702I04-23H12P300?
Samples start from 1 pc. Production MOQ and lead time depend on quantity and any customization (FPC length, backlight, touch), and are agreed per project with our sales team. Send your annual volume and target date for a quote.
